| Type: | JC-100 | JC-300 | JC-800 |
| Volume: | 100L | 300L | 800L |
| Heating Power: | 9kw | 18kw | 27kw |
Send E-mail
Consult Now
Brief Introduction：
Widely used in various types of food processing industry, hotels, restaurants, industrial and mining enterprises, army authorities, college canteens and other, for porridge, soup, cooking and stew . At the same time, it can be used in candy, cakes, drinks, candied fruit,jam and so on food processing and brewing, wine making, pharmaceutical and other daily-use chemical industry.
Feature：
Three heating ways available, electric, gas and steam.
Two types of structure, vertical or tilting.
With function of mixing and scraper.
Different volume, 50L, 100L , 200L, 300L....1000L.
Large heating area, high thermal efficiency, uniform heating, short liquid boiling time, easy control and so on.
Working Principle:
There’s interlayer between kettle body and pot wall, which is filled with conduction oil. When it is heated, then the materials in the pot will get cooked.
Technical Data:
| Volume（L） |
50 |
100 |
200 |
300 |
400 |
500 |
600 |
800 |
1000 |
| Caliber（mm） |
Φ600 |
Φ700 |
Φ800 |
Φ900 |
Φ1000 |
Φ1100 |
Φ1200 |
Φ1400 |
Φ1500 |
| Kettle Height（mm） |
400 |
450 |
580 |
630 |
680 |
730 |
780 |
830 |
900 |
| Heat Transfer Area（m2） |
0.45 |
0.58 |
1.12 |
1.42 |
1.75 |
2 |
2.3 |
3.2 |
3.9 |
| Heating Power（kw） |
9 |
9 |
15 |
18 |
18 |
24 |
24 |
27 |
30 |
| Heat Conduction Oil（L） |
30 |
36 |
45 |
60 |
70 |
80 |
100 |
200 |
250 |
| Working Pressure |
≤0.09Mpa（Adjustable） |
||||||||
| Stirring Rate |
36 r/min（Adjustable） |
||||||||
| Stirring Motor Power（kw） |
0.75 |
0.75 |
1.1 |
1.5 |
1.5 |
2.2 |
2.2 |
3 |
4 |
